This AHD wide-angle vehicle camera is designed as an industrial vision component for commercial vehicles, fleet safety systems, and OEM transportation platforms. Built around a rugged full-metal housing and an adjustable 360-degree mounting structure, the camera provides reliable real-time video capture for blind-spot monitoring, side-view assistance, reverse observation, and multi-camera vehicle surveillance architectures.
The product is intended for integration into truck, bus, logistics, municipal, and specialty vehicle platforms, where continuous operation, vibration resistance, and environmental sealing are mandatory. Rather than consumer-grade aesthetics, the design prioritizes signal stability, mechanical durability, and long-term field reliability.
The camera adopts an AHD high-definition imaging architecture, supporting 720P and 1080P video output over coaxial transmission. Combined with a wide-angle glass lens assembly, the system enables broad field-of-view coverage while maintaining geometric consistency required for professional driving assistance displays.
A multi-element optical glass lens is used to control distortion and light dispersion, allowing the camera to perform consistently across varied lighting conditions. In low-light or night environments, the integrated infrared night-vision system automatically enhances scene visibility, ensuring clear object recognition at vehicle perimeters.
This makes the camera suitable for:
The camera housing is manufactured from high-strength metal alloy, providing superior resistance to impact, vibration, and thermal cycling compared to plastic enclosures. The bracket and body are designed as a single reinforced structure, enabling stable installation on vehicle exteriors.
A key engineering feature is the 360-degree adjustable lens orientation, allowing precise angle calibration during installation. This flexibility simplifies deployment across different vehicle models and mounting positions, including:
The streamlined housing profile reduces wind resistance and minimizes contamination accumulation during high-speed driving or long-distance operation.
Designed for harsh transportation environments, the camera meets IP69K-level waterproof and dustproof performance, enabling it to withstand:
The sealed structure and internal gluing process enhance long-term resistance against moisture ingress and internal corrosion. Shockproof construction ensures stable image output even under continuous vibration or uneven road conditions.
The camera supports AHD video signal output, compatible with mainstream commercial vehicle monitors, MDVR systems, and multi-channel recording units. Standardized connectors and wiring options allow seamless integration into existing vehicle electrical architectures.
Typical integration scenarios include:
The product is engineered for OEM and ODM projects, offering consistent electrical characteristics suitable for batch deployment and long-term maintenance planning.
This camera is widely used in:
By providing stable wide-angle video input, it helps reduce blind-spot accidents, improve driver awareness, and support compliance with commercial vehicle safety regulations.
| Item | Specification |
|---|---|
| Camera Type | AHD Vehicle Camera |
| Image Sensor | AHD Sensor (Optional Sony Solution) |
| Video Resolution | 720P / 1080P (Selectable) |
| Video Signal | AHD (Coaxial) |
| Lens Type | Multi-layer Optical Glass Lens |
| Field of View | Wide Angle (Approx. 140°-170° optional) |
| Night Vision | Infrared Night Vision with Automatic Switching |
| Minimum Illumination | ≤ 0.01 Lux (IR On) |
| Housing Material | Full Metal Alloy |
| Mounting | Adjustable Bracket, 360° Rotation |
| Waterproof Rating | IP69K |
| Shock & Vibration | Automotive-Grade Shockproof Design |
| Operating Voltage | DC 12V (Optional 9-36V for heavy vehicles) |
| Operating Temperature | −30°C to +70°C |
| Connector Type | Aviation Connector / AV (Optional) |
| Installation Position | Side / Rear / Front / Corner |
| Application Vehicles | Truck, Bus, Fleet, Special Vehicles |
| OEM / ODM Support | Yes |
